Pump Type Displacement cc/rev. Pressure In Bar Max. Speed rpm A B C (Suction Port) D (Delivery Port)
mm mm side rear
CPDR 30-44 44.0 cc 270 2000 58 190 G 1" G 1"
CPDR 30-55 55.0 cc 250 1800 58 198 G 1" G 1"
MCP 30-65 65.0 cc 230 1800 58 204
MCP 30-83 83.0 cc 200 1700 58 215 G 1-1/4" G 1-1/4"
